Product Introduction
Nickel ion electrochemical sensor test strip 2
The M series test strips introduce key technologies of biomedical blood glucose test strips, integrating electrochemical three-electrode system, microfluidics and drug coating technology on each sensor. Using a consistent production process, the quality of each tube sensor test strip is strictly controlled, and laboratory ppb-level detection can be achieved within a few minutes. With the portable electrochemical metal ion detection system MAS G1, users do not need complicated pre-treatment and calibration procedures, and do not need to worry about sample cross-contamination or interference caused by human operation, and can obtain the most real-time data in a highly efficient way.
SPECIFICATION
- model
- Ni-M001100
Detection species Divalent nickel ion - length
- 30 mm
- width
- 12 mm
- Microchannel volume
- 10 uL
- Calibration line concentration range
- 0.10-1.00 mg/L
- Minimum detection limit
- 0.07 mg/L
- Analysis time
- 123 seconds
Technical Information
The left picture shows the electrochemical voltammogram of nickel ion concentrations (0.10-1.00 mg/L) in the wastewater of an electroplating plant detected by using a nickel ion sensor (Ni-M010100) and an electrochemical metal ion detection system (MAS G1).
There is a very obvious nickel ion current signal near -1250 mV. The signal increases with the increase of nickel ion concentration. After regression analysis of the current signal intensity and concentration, R2 > 0.99, indicating that this sensor can accurately quantify in real samples.
The quantitative range of Ni-M010100 (0.10-1.00 mg/L) is set for mass production to comply with the current Taiwan industrial effluent control standards. If you have quantitative requirements below 0.10 mg/L or above 1.00 mg/L, please call or write to our company for further discussion.
FEATURES
- 免加前處理藥劑，拿試片輕沾水樣即可
- 免建校正檢量線
- 具微流道反應槽，內已預塗布反應藥劑(非管制毒化物)
- 僅需一滴樣品量
- 電化學三電極系統檢測(非光學法)
- 試片材質可回收，不會造成環境負擔
瑞準科技ACCUSENSING 的金屬離子感測器，改善了市面上現場水質快篩工具/儀器檢測重金屬時沒有數值、須加藥劑前處理、操作繁瑣耗時、攜帶不便等問題，經過不斷的研發改良與真實工廠水樣測試，目前產品已獲得行政院環保署、台塑集團半導體製造商南亞科技、北部知名電鍍商擁強股份有限公司、菲律賓MAPUA大學等國內、外知名客戶採用。
